ORTIS PRO
ORTIS PRO represents the intermediate configuration that allows you an average daily production of 10-15 models with a working area of 800 mm diameter and 1200 mm height. All the production needs are satisfied by this system that offers you to choose between different variants to the standard configuration.
The system is installed on an industrial floor with walls and partitions that delimit its access area; inside this area the robot, the turntable and the presetting laser (that measures the real tool length) are fixed on the ground. In standard configuration the tool change is manual.
Specifications
Robot type
ABB, 6 axes, 20 kg payload on the wrist, working area of 1600 mm
ABB, 6 axes, 20 kg payload on the wrist, working area of 1600 mm
Turntable
In-house designed, it is the 7th interpolated axis. Rotating table plate dimension 700x700mm, 60 rpm.
Possibility to have an additional turntable or fixed table to increase productivity.
In-house designed, it is the 7th interpolated axis. Rotating table plate dimension 700x700mm, 60 rpm.
Possibility to have an additional turntable or fixed table to increase productivity.
Laser calibration
The standard setup includes a laser guide to perform automatic tool length calibration.
The standard setup includes a laser guide to perform automatic tool length calibration.
Working volume
Blocks up to:
· Corsets – Diam 800x(H)1200 mm
· AFO / KAFO – 350x300x(H)1000 mm
· SEATING SYSTEMS – 800x800x(H)800 mm
Blocks up to:
· Corsets – Diam 800x(H)1200 mm
· AFO / KAFO – 350x300x(H)1000 mm
· SEATING SYSTEMS – 800x800x(H)800 mm
Compressed air
Minimum 6 bar
Minimum 6 bar
System programming
A license of our ARPP® software ships with the system. ARPP® is powered by 5-axis a tool path generator (ARPPCAM), and allows for a precise ahead-of-time 3D simulation of the milling and material removal process.
A license of our ARPP® software ships with the system. ARPP® is powered by 5-axis a tool path generator (ARPPCAM), and allows for a precise ahead-of-time 3D simulation of the milling and material removal process.
An open system
ORTIS can be used with any 3D scanner or software that makes use of industry-standard formats (STL, AOP, VRML, …).
ORTIS can be used with any 3D scanner or software that makes use of industry-standard formats (STL, AOP, VRML, …).
Bulk size
System minimum area: 3000x3000x2700 mm
Contol unit area: 1000x1000x2000 mm.
System minimum area: 3000x3000x2700 mm
Contol unit area: 1000x1000x2000 mm.
Weight
Robot + base : 550 kg, Turntable: 270 kg
Control unit: 250 kg
Robot + base : 550 kg, Turntable: 270 kg
Control unit: 250 kg
Power supply
380VAC, three phase, 50-60Hz, 12 KVA
(4,5 kw average consumption)
380VAC, three phase, 50-60Hz, 12 KVA
(4,5 kw average consumption)
